Spesifikasi Terperinci

• Dimensi

  add remove
  • Panjang:
    2410 mm
  • Tinggi Jok:
    720 mm
  • Garpu (kepala kemudi) (derajat):
    26
  • Jejak:
    170 mm
  • Jarak roda:
    1625 mm
  • Ban, spesifikasi depan:
    130/60B19 M/C 61H
  • Ban, spesifikasi belakang:
    180/55B18 M/C 80H
  • Kapasitas bahan bakar:
    22.7 l
  • Kapasitas oil (dengan filter):
    4.4 l
  • Bobot, saat dikirim:
    375 kg
  • Bobot, berfungsi baik:
    392.81 kg
  • Luggage capacity – volume:
    2.2 cu ft (0.062 m3)
  • Tire, type:
    Dunlop® Harley-Davidson Series, bias blackwall front and rear
• Mesin

  add remove
  • Mesin:
    Milwaukee-Eight® VVT 121
  • Diameter:
    103.5 mm
  • Jarak piston:
    117.5 mm
  • Kapasitas:
    1977 cm³
  • Rasio kompresi:
    11.4:1
  • Sistem bahan bakar:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Pembuangan:
    2-1-2 dual exhaust
• Performa

  add remove
  • Metode Pengujian Torsi Mesin:
    J1349
  • Torsi mesin:
    189 Nm
  • Torsi mesin (RPM):
    3000
  • Horsepower:
    115 HP / 86 kW @ 4500 rpm
  • Sudut kemiringan, kanan (derajat):
    32
  • Sudut kemiringan, kiri (derajat):
    32
  • Fuel economy testing method:
    Estimated City/Hwy
  • Fuel economy:
    45 mpg (5.1 l/100 km)
• Powertrain

  add remove
  • Penggerak utama:
    Chain, 34/46 ratio
  • Rasio roda gigi (menyeluruh) Ke-1:
    9.593
  • Rasio roda gigi (menyeluruh) Ke-2:
    6.65
  • Rasio roda gigi (menyeluruh) Ke-3:
    4.938
  • Rasio roda gigi (menyeluruh) Ke-4:
    4
  • Rasio roda gigi (menyeluruh) Ke-5:
    3.407
  • Rasio roda gigi (menyeluruh) Ke-6:
    2.875
• Sasis

  add remove
  • Garpu Depan:
    47 mm Inverted 1x1 Front Forks
  • Shock Belakang:
    Dual adjustable emulsions suspension with remote preload adjustment on the left shock, and threaded preload on the right shock
  • Roda, jenis depan:
    Combo Cast Laced
  • Roda, jenis belakang:
    Combo Cast Laced
  • Rem, Jenis Rotor:
    Dual floating rotors (front), fixed rotor (rear)
  • Rem, jenis kaliper:
    32 mm, 4-piston fixed dual radially mounted front, and single axially mounted rear
• Infotainment

  add remove
  • Infotainment system:
    Skyline™ OS
  • Jenis:
    Full Color TFT
  • Watts per channel:
    125
  • Speakers:
    4
  • Speaker size:
    Two 6.5in fairing speakers, and two 5x7in saddlebag speakers
  • Headset specifications (if equipped):
    Harley-Davidson Packtalk Edge wireless Bluetooth® headset
  • AM:
    Standard
  • FM:
    Standard
  • SD Card, Flash Drive and MP3 - via USB Connection:
    Supported
  • Bahasa:
    Arabic, Bahasa (Indonesian), Catalan, Chinese (Simplified/Traditional), Czech, Danish, Dutch, English (UK/USA default), Finnish, French (Canada/France), German, Hebrew, Hungarian, Indonesian, Italian, Japanese, Korean, Malay, Norwegian, Polish, Portuguese
  • Hands-free mobile phone — via Bluetooth:
    Standard
  • Voice recognition: phone functions only:
    Phone dependent
  • Text-to-Speech (TTS) languages:
    Phone dependent
  • Rider / passenger intercom:
    Standard (Passenger Headset Sold Separately)
  • Layar informasi kendaraan (suhu udara, tekanan oli, dan eitms):
    Standard
  • USB:
    USB-C/MTP/iPod/iPhone, any device with proper adapters to the electric power outlet located in the inner fairing storage
  • Bluetooth:
    Phone/Media Player, Headset
