Spesifikasi Terperinci

• Dimensi

  add remove
  • Panjang:
    2270 mm
  • Jarak bebas ke tanah:
    175 mm
  • Garpu (kepala kemudi) (derajat):
    25
  • Jejak:
    108 mm
  • Jarak roda:
    1585 mm
  • Ban, spesifikasi depan:
    120/70R19 60V
  • Ban, spesifikasi belakang:
    170/60R17 72V
  • Kapasitas bahan bakar:
    21.2 l
  • Kapasitas oil (dengan filter):
    4.3 l
  • Bobot, saat dikirim:
    242 kg
  • Bobot, berfungsi baik:
    258.09 kg
• Mesin

  add remove
  • Mesin:
    Revolution® Max 1250
  • Diameter:
    105 mm
  • Jarak piston:
    72.3 mm
  • Kapasitas:
    1252 cm³
  • Rasio kompresi:
    13.0:1
  • Sistem bahan bakar:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Pembuangan:
    2-into-1-into-1; catalyst in header
• Performa

  add remove
  • Metode Pengujian Torsi Mesin:
    J1349
  • Torsi mesin:
    129 Nm
  • Torsi mesin (RPM):
    6750
  • Sudut kemiringan, kanan (derajat):
    42
  • Sudut kemiringan, kiri (derajat):
    42
  • Fuel economy testing method:
    Estimated City/Hwy
  • Fuel economy:
    46 mpg (5.1 l/100 km)
• Powertrain

  add remove
  • Penggerak utama:
    Gear, 49/89 ratio
  • Rasio roda gigi (menyeluruh) Ke-1:
    13.11
  • Rasio roda gigi (menyeluruh) Ke-2:
    9.687
  • Rasio roda gigi (menyeluruh) Ke-3:
    7.509
  • Rasio roda gigi (menyeluruh) Ke-4:
    6.057
  • Rasio roda gigi (menyeluruh) Ke-5:
    5.08
  • Rasio roda gigi (menyeluruh) Ke-6:
    4.436
• Sasis

  add remove
  • Garpu Depan:
    47mm inverted fork with electronically adjustable semi-active damping control. Aluminum fork triple clamps
  • Shock Belakang:
    Linkage-mounted monoshock with automatic electronic preload control and semi-active compression & rebound damping
  • Wheels, optional style type:
    Annodized aluminum tubeless laced
  • Roda, jenis depan:
    Aluminum cast, satin black
  • Roda, jenis belakang:
    Aluminum cast, satin black
  • Rem, Jenis Rotor:
    Front: dual rotor, floating, tower- mounted; Rear: solid uniform expansion rotor
  • Rem, jenis kaliper:
    Front: radially mounted, monoblock, 4-piston caliper; Rear: floating, single piston caliper
• Infotainment

  add remove
  • Jenis:
    Color TFT w/ Touch
  • Headset specifications (if equipped):
    Bluetooth
  • Hands-free mobile phone — via Bluetooth:
    Standard
  • Voice Recognition Languages: Phone functions only:
    Phone dependent
  • Voice Recognition Languages: Tuner / Media / Navigation:
    Phone dependent
  • Text-to-Speech (TTS) languages:
    Phone dependent
  • Rider / passenger intercom:
    Headset function only
  • Layar informasi kendaraan (suhu udara, tekanan oli, dan eitms):
    TPMS, Engine temp, Battery Voltage, Ambient Air Temp
  • USB:
    Charging and Instrument update, USB-C, 5V, 3A
  • Bluetooth:
    Phone/Media Supported
