Spesifikasi Terperinci

• Dimensi

  add remove
  • Panjang:
    2410 mm
  • Tinggi Jok:
    715 mm
  • Garpu (kepala kemudi) (derajat):
    26
  • Jejak:
    170 mm
  • Jarak roda:
    1625 mm
  • Ban, spesifikasi depan:
    130/60B19 61H
  • Ban, spesifikasi belakang:
    BW 180/55B18 80H
  • Kapasitas bahan bakar:
    22.7 l
  • Kapasitas oil (dengan filter):
    4.4 l
  • Bobot, saat dikirim:
    351 kg
  • Bobot, berfungsi baik:
    367.86 kg
  • Luggage capacity – volume:
    2.3 cu ft (0.064 m³)
  • Tire, type:
    Dunlop® Harley-Davidson Series, bias blackwall front and rear
• Mesin

  add remove
  • Mesin:
    Milwaukee-Eight® 117
  • Diameter:
    103.5 mm
  • Jarak piston:
    114.3 mm
  • Kapasitas:
    1923 cm³
  • Rasio kompresi:
    10.3:1
  • Sistem bahan bakar:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Pembuangan:
    Chrome, 2-1-2 dual exhaust with tapered mufflers
• Performa

  add remove
  • Metode Pengujian Torsi Mesin:
    J1349
  • Torsi mesin:
    176 Nm
  • Torsi mesin (RPM):
    3,250
  • Sudut kemiringan, kanan (derajat):
    31
  • Sudut kemiringan, kiri (derajat):
    29
  • Fuel economy testing method:
    Estimated City/Hwy
  • Fuel economy:
    44 mpg (5.3 l/100 km)
• Powertrain

  add remove
  • Penggerak utama:
    Chain, 34/46 ratio
  • Rasio roda gigi (menyeluruh) Ke-1:
    9.593
  • Rasio roda gigi (menyeluruh) Ke-2:
    6.65
  • Rasio roda gigi (menyeluruh) Ke-3:
    4.938
  • Rasio roda gigi (menyeluruh) Ke-4:
    4
  • Rasio roda gigi (menyeluruh) Ke-5:
    3.407
  • Rasio roda gigi (menyeluruh) Ke-6:
    2.875
• Sasis

  add remove
  • Garpu Depan:
    49mm Dual Bending Valve
  • Shock Belakang:
    3 in. Dual Outboard Emulsion with Preload Adjustability
  • Roda, jenis depan:
    Cast aluminum
  • Roda, jenis belakang:
    Cast aluminum
  • Rem, Jenis Rotor:
    Dual floating rotors (front), fixed rotor (rear)
  • Rem, jenis kaliper:
    1.3 in., 4-piston fixed dual axially mounted front, and single axially mounted rear
• Listrik

  add remove
  • Lampu (sesuai peraturan negara), lampu indikator:
    LED headlamp, tail/stop, front signal lights and rear turn signals
  • Alat pengukur:
    Digital gauges integrated within the display
• Infotainment

  add remove
  • Screen size:
    12.3 in
  • Infotainment system:
    Skyline™ OS
  • Jenis:
    Full Color TFT
  • Watts per channel:
    50
  • Speakers:
    2
  • Speaker size:
    Two 5.25 in. fairing speakers
  • Headset specifications (if equipped):
    Harley-Davidson Packtalk Edge wireless Bluetooth® headset
  • AM:
    Standard
  • FM:
    Standard
  • SD Card, Flash Drive and MP3 - via USB Connection:
    Supported
  • Bahasa:
    Arabic, Bahasa (Indonesian), Catalan, Chinese (Simplified/Traditional), Czech, Danish, Dutch, English (UK/USA default), Finnish, French (Canada/France), German, Hebrew, Hungarian, Indonesian, Italian, Japanese, Korean, Malay, Norwegian, Polish, Portuguese
  • Hands-free mobile phone — via Bluetooth:
    Standard
  • Voice recognition: phone functions only:
    Phone dependent
  • Voice Recognition Languages: Tuner / Media / Navigation:
    Phone dependent
  • Text-to-Speech (TTS) languages:
    Arabic, Bahasa (Indonesian), Catalan, Chinese (Simplified/Traditional), Czech, Danish, Dutch, English (UK/USA default), Finnish, French (Canada/France), German, Hebrew, Hungarian, Indonesian, Italian, Japanese, Korean, Malay, Norwegian, Polish, Portuguese
  • Rider / passenger intercom:
    Standard (passenger headset sold separately), VOX is available for HD headsets
  • Layar informasi kendaraan (suhu udara, tekanan oli, dan eitms):
    Standard
  • USB:
    USB-C/MTP/iPod/iPhone, any device with proper adapters to the electric power outlet located in the inner fairing storage.
  • Bluetooth:
    Phone/Media Player, Headset
