Spesifikasi Terperinci

• Dimensi

  add remove
  • Panjang:
    2415 mm
  • Overall width:
    930 mm
  • Overall height:
    1468 mm
  • Tinggi Jok:
    687 mm
  • Jarak bebas ke tanah:
    118 mm
  • Garpu (kepala kemudi) (derajat):
    30
  • Jejak:
    145 mm
  • Jarak roda:
    1630 mm
  • Ban, spesifikasi depan:
    130/90B16,73H,BW
  • Ban, spesifikasi belakang:
    150/80B16,77H,BW
  • Kapasitas bahan bakar:
    18.9 l
  • Kapasitas oil (dengan filter):
    4.0 l
  • Bobot, saat dikirim:
    322 kg
  • Bobot, berfungsi baik:
    336.57 kg
  • Luggage capacity – volume:
    1.5 cu ft (0.043 m³)
  • Tire, type:
    Dunlop® Harley-Davidson Series, bias blackwall front and rear
  • Fork angle:
    30
  • Reserve fuel capacity, fuel injection:
    3.8 l
  • Gross axle weight rating, front:
    204 kg
  • Gross axle weight rating, rear:
    331 kg
  • Transmission capacity:
    1 qt. (.95 l )
  • Primary chain case capacity:
    1.25 qt. (1.18 l )
• Mesin

  add remove
  • Mesin:
    Milwaukee-Eight® 114
  • Diameter:
    102 mm
  • Jarak piston:
    114.3 mm
  • Kapasitas:
    1868 cm³
  • Rasio kompresi:
    10.5:1
  • Sistem bahan bakar:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Air cleaner:
    Screamin' Eagle® round high-flow air cleaner with oiled-cotton filter element.
  • Pembuangan:
    2-into-2 shorty dual; catalyst in muffler
  • Lubrication system:
    Pressurized, dry-sump with oil cooler
• Performa

  add remove
  • Metode Pengujian Torsi Mesin:
    J1349
  • Torsi mesin:
    161 Nm
  • Torsi mesin (RPM):
    3,000
  • Horsepower:
    94 HP / 70 kW @ 4750 rpm
  • Sudut kemiringan, kanan (derajat):
    27.4
  • Sudut kemiringan, kiri (derajat):
    27.4
  • Fuel economy testing method:
    Estimated City/Hwy
  • Fuel economy:
    47 mpg (5 l/100 km)
  • Lean angle testing method:
    J1168
• Powertrain

  add remove
  • Penggerak utama:
    Chain, 34/46 ratio
  • Rasio roda gigi (menyeluruh) Ke-1:
    9.311
  • Rasio roda gigi (menyeluruh) Ke-2:
    6.454
  • Rasio roda gigi (menyeluruh) Ke-3:
    4.793
  • Rasio roda gigi (menyeluruh) Ke-4:
    3.882
  • Rasio roda gigi (menyeluruh) Ke-5:
    3.307
  • Rasio roda gigi (menyeluruh) Ke-6:
    2.79
  • Final drive:
    Belt, 32/66 ratio
  • Clutch:
    Mechanical, 10 plate wet, assist & conventional
  • Transmission:
    6-Speed Cruise Drive®
• Sasis

  add remove
  • Garpu Depan:
    Dual-bending valve 49 mm telescopic with aluminum fork triple clamps; dual rate spring; "beer can" covers
  • Shock Belakang:
    Hidden, free piston, coil-over monoshock; 43mm stroke; cam-style preload adjustment
  • Roda, jenis depan:
    Chrome Steel Laced
  • Roda, jenis belakang:
    Chrome Steel Laced
  • Rem, Jenis Rotor:
    Solid, uniform expansion rotors
  • Rem, jenis kaliper:
    4-piston fixed front and 2-piston floating rear
  • Frame:
    Mild steel, tubular frame; rectangular section backbone; stamped, cast, and forged junctions; MIG welded; aluminum forged fender supports
  • Swingarm:
    Mild steel, tubular sections, stamped x-member, forged axle junctions; MIG welded; removable belt spacer
• Listrik

  add remove
  • Lights (as per country regulation), Headlamp:
    All LED, low beam, high beam and signature position lamp
  • Lights (as per country regulation), Tail/Stop:
    Incandescent Zeppelin tail lamp
  • Lights, front signal lights:
    Incandescent bullets
  • Lights, rear turn signals:
    Incandescent bullet light bar
  • Alat pengukur:
    5-inch analog speedometer with digital gear, odometer, fuel level, clock, trip, range and tachometer indication
  • Battery:
    Sealed, maintenance-free, absorbed glass mat (AGM) battery, 12V, 17.5Ah, 310 CCA at 0°F
  • Charging:
    Three-phase, 42 Amp system (390 Watts @13 Volts, 1000 rpm, 546 Watts max power @ 13 Volts, 2000 rpm)
  • Starting:
    1.6 kW electric with solenoid shift starter motor engagement
  • Auxiliary lamps:
    LED fog
  • Electric power outlet:
    USB A-type; output 5V at 2.4A
