Spesifikasi Terperinci

• Dimensi

  add remove
  • Panjang:
    2270 mm
  • Tinggi Jok:
    705 mm
  • Garpu (kepala kemudi) (derajat):
    30
  • Jejak:
    137 mm
  • Jarak roda:
    1556 mm
  • Ban, spesifikasi depan:
    100/90-19 57H
  • Ban, spesifikasi belakang:
    150/80B16 77H
  • Kapasitas bahan bakar:
    11.7 l
  • Kapasitas oil (dengan filter):
    2.9 l
  • Bobot, saat dikirim:
    211 kg
  • Bobot, berfungsi baik:
    487.16 kg
  • Tire, type:
    Dunlop™ Harley-Davidson Series Bias Blackwall
• Mesin

  add remove
  • Mesin:
    Revolution® Max 975T
  • Diameter:
    97 mm
  • Jarak piston:
    66 mm
  • Kapasitas:
    975 cm³
  • Rasio kompresi:
    12:01
  • Sistem bahan bakar:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Pembuangan:
    2-into-1; catalyst in header
• Performa

  add remove
  • Metode Pengujian Torsi Mesin:
    EC 134/2014
  • Torsi mesin:
    95 Nm
  • Torsi mesin (RPM):
    5000
  • Horsepower:
    89 HP / 66 kW @ 7500 rpm
  • Sudut kemiringan, kanan (derajat):
    32
  • Sudut kemiringan, kiri (derajat):
    32
  • Fuel economy testing method:
    EU 134/2014
  • Fuel economy:
    4.5 l/100 km
  • CO₂ emissions testing method:
    EU 134/2014
  • CO₂ emissions :
    126 g/km CO₂
• Powertrain

  add remove
  • Penggerak utama:
    Gear, 49/89 ratio
  • Rasio roda gigi (menyeluruh) Ke-1:
    12.21
  • Rasio roda gigi (menyeluruh) Ke-2:
    9.022
  • Rasio roda gigi (menyeluruh) Ke-3:
    6.994
  • Rasio roda gigi (menyeluruh) Ke-4:
    5.641
  • Rasio roda gigi (menyeluruh) Ke-5:
    4.731
  • Rasio roda gigi (menyeluruh) Ke-6:
    4.131
• Sasis

  add remove
  • Garpu Depan:
    41mm SHOWA™ Dual Bending Valve conventional forks. Aluminum fork triple clamps.
  • Shock Belakang:
    Rear suspension is dual outboard, direct-acting (no linkage) emulsion technology shock absorbers with coil springs and a threaded collar for pre-load adjustment.
  • Roda, jenis depan:
    Aluminum cast, satin black
  • Roda, jenis belakang:
    Aluminum cast, satin black
  • Rem, Jenis Rotor:
    Front: single rotor, floating, hub - mounted; Rear: solid uniform expansion rotor
  • Rem, jenis kaliper:
    Front: axially mounted, 4-piston caliper; Rear: floating, single piston caliper
• Listrik

  add remove
  • Lampu (sesuai peraturan negara), lampu indikator:
    All LED headlamp, low and high beam with signature position lighting; All LED rear lighting; LED bullet turn signals
  • Alat pengukur:
    4-inch viewable round gauge area analog display with, Speedometer, L/R turn Indication, Traction Control Indication, Coolant Temperature Alert, ABS alert, Fog Lamp Indication, Battery Voltage Alert, High Beam Indicator, Low Fuel Indication, Rear-ABS Disab
• Infotainment

  add remove
  • Jenis:
    Analog display
  • Bahasa:
    English (default)
  • Layar informasi kendaraan (suhu udara, tekanan oli, dan eitms):
    Total Odometer (Selectable Miles or km), Trip A/B, Gear Position Indication, Fuel Range, 12/24 Hr Clock, Digital Tachometer, Segmented Feul Level, Ride Mode Indication
